How a Mechanical Watch Works, Explained Properly

A mechanical watch works thanks to a series of gears that transform the energy of a coiled spring into a regular, controlled motion. The mainspring is wound by hand or automatically and releases its energy through the barrel, the wheel train and the escapement, until the hands move with precision.

In this article

1. The energy: where it comes from and where it goes
2. The barrel and the mainspring
3. The wheel train
4. The escapement: the heart of the mechanism
5. The balance wheel and the hairspring: measuring time
6. Manual vs automatic winding
7. Why mechanical watchmaking still makes sense
8. FAQ

1. The energy: where it comes from and where it goes

It all begins with a simple gesture: turning the crown, or moving your wrist. In both cases the goal is the same — to compress a metal spring that, as it slowly unwinds, drives the entire mechanism beneath it.

Unlike a quartz watch, a mechanical watch needs no electricity. The energy is purely mechanical: a physical build-up of tension that converts, gear after gear, into the ticking of the hands.

2. The barrel and the mainspring

The mainspring is a thin steel blade coiled inside a circular container called the barrel. When you wind the watch, the spring coils further; when it releases, it does so gradually, feeding energy to the mechanism.

Power reserve

The capacity of the spring determines the power reserve: on average 40–48 hours for a standard watch, up to several days for movements with a twin barrel.

3. The wheel train

The wheel train is a chain of gears that transmits the force from the barrel all the way to the escapement. The end result is that the seconds wheel completes one turn per minute, the minutes wheel one turn per hour, and the hours wheel one turn every 12 hours.

4. The escapement: the heart of the mechanism

The escapement regulates the release of the stored energy and delivers small impulses to the balance wheel to keep it oscillating. The most common type is the lever escapement: it locks and releases the escape wheel in sync with the balance wheel, producing the characteristic tick-tock.

Deep dive: What the escapement is — Lezioni di Tempo Glossary

5. The balance wheel and the hairspring: measuring time

The balance wheel is a wheel that swings back and forth at a defined frequency, controlled by a small hairspring. A 21,600 bph movement makes three oscillations per second; a 28,800 bph one makes four. Regulating a mechanical watch means adjusting the active length of the hairspring.

See also: 21,600 or 28,800 beats: what really changes in the movement

6. Manual vs automatic winding

There are two ways to compress the mainspring: by hand, turning the crown, or automatically, thanks to a rotor that harnesses the movements of the wrist.

See also: Automatic or manual winding: the real differences, advantages and limits

7. Why mechanical watchmaking still makes sense

A mechanical watch can be seen working, is wound with a physical gesture, and ages alongside the person who wears it. It is not merely an object that measures time: it is proof that complexity can be contained within a few centimetres, with no electricity and no screen.

FAQ

Does a mechanical watch need to be wound every day?

Not necessarily. Most automatic movements have a reserve of 40–48 hours. If you don't wear it for several days it will stop and will need to be rewound.

What is the difference between a mechanical watch and a quartz one?

Quartz uses a battery and a crystal that vibrates at a constant frequency. A mechanical watch uses the force of a spring and a system of gears. Quartz loses a few seconds per month; a mechanical watch a few seconds per day.

Is the tick-tock of a mechanical watch always the same?

It depends on the frequency. A 21,600 bph movement produces 3 ticks per second, a 28,800 bph one produces 4.

What happens if a mechanical watch is dropped?

A hard knock can damage the balance wheel or the gear pivots. Modern movements often include anti-shock systems such as Incabloc or KIF.

In short

• The mainspring stores energy and releases it slowly through the barrel
• The wheel train transmits the force and sets the rotation speeds of each hand
• The escapement regulates the release of energy and keeps the balance wheel oscillating
• The balance wheel and hairspring measure time through their regular oscillations
• Winding can be manual (crown) or automatic (rotor): the underlying mechanism is identical
